stage
Item No. NF-MH382
Voltage AC100-240V 50/60Hz
Bulb 382W Osram
Power 600W
Color temperature 8500K
Moving Head Lights Optical System:
- Tailored OSRAM SIRIUS HRI 382W lamp dj lighting with a lifespan of approximately 3,000 hours.
- Equipped with Italian heat-resistant glass for efficient heat dissipation.
- Utilizes a specialized optical lens structure with a diameter of up to 152mm.
- Offers a beam angle range from 2 to 50 degrees, with a frost option.
- Features an automatic beam and prism focusing function.
Display System:
- Incorporates a high-resolution 20 million-pixel LCD touchscreen display with a sleep mode.
- Displays lamp life and device usage time.
- Includes an automatic error testing function.
- Allows for control via both LCD touchscreen and knobs.
382W CMY Stage Lights Control System:
- Adheres to the international standard DMX512.
- Offers 22 control channels.
- Supports various control modes including DMX, random, auto, voice, and sleep modes.
- Operates on a high-tech constant current board with 36V/12V voltage.
- Ensures stable signal transmission through built-in high-quality magnetic components.
- Features data line antifreeze compliance with CE20/22 standards.
DJ Lighting Color System:
- Utilizes imported Italian high-temperature materials and advanced German coating technology.
- Features a fixed color wheel with 10 colors plus an open and CTO filter.
- Includes a 6-color rainbow wheel with various color effects and dynamic rotation options.
- Automatic error correction at any angle through hall and magnet positioning.
Gobo System:
- Utilizes a metal gobo wheel with 10 gobos plus an open position.
- Offers 4 adjustable beam angles for water, shake, and slow-fast rotation effects.
- Employs imported Italian refractory metal materials.
- Automatic error correction at any angle through hall and magnet positioning.
Frost System:
- Independent single-sided high penetration frost lens.
- Provides various frost effects with an adjustable angle, up to 50 degrees.
Voltage
AC100-240V 50/60Hz
Bulb
382W Osram
Power
600W
Color temperature
(8500K)
Ballast
Electronic ballast
Channel
18 channels
Color
14 colors + white light, with rotating rainbow effect
Pattern
9 metal + 4 glass patterns + white light
Prism disk 1
8 prism
Prism disk 2
(6+12+24) honeycomb prism. Combinable prism colorful effects
Atomization
0-100% linear atomization
Strobe
0.5-14 times/second, multiple strobe effects
Optics
High-precision glass optical lens, linear zoom 0-20 degrees
XY axis
three-phase motor
Movement angle
horizontal 540 degrees, 8/16Bit resolution, vertical 270 degrees, 8/16Bit resolution
Protection level
IP20
Net weight
19Kg
Gross weight
21kg
Packing size
50x48x60CM
