Item No. A3-815D A3-910C A3-810C A3-808B A3-806B A3-705A A3-704A A3-703A
Red Laser R4000mw/638nm R3000mw/638nm R3000mw/638nm R2000mw/638nm R2000mw/638nm R1200mw/638nm R1000mw/638nm R700mw/638nm
Green Laser G4500mw/520nm G3000mw/525nm G3000mw/525nm G2000mw/520nm G1500mw/525nm G1400mw/520nm G1400mw/520nm G800mw/525nm
Blue Laser B7000nw/450nm B4000nw/450nm B4000nw/450nm B4000nw/450nm B2500nw/450nm B2400nw/450nm B2000nw/450nm B1500nw/450nm
Scanning system 30kpps 25kpps 25kpps 20kpps 20kpps 15kpps 15kpps 15kpps
Control Mode
Our The NewfeelLaser A3 outdoor lighting laser projector series cater to the workflow of outdoor lighting designers.Offering easy control in three different ways:
1.Console Mode - Over DMX or ArtNET, directly from a console. And we include over 1,500 FREE outdoor laser light projector gobos for you to control, directly on the dj laser lights.
2.Streaming ModeāAllowing for direct control from a PC using Pangolinās QuickShow or Beyond Software (over Ethernet).
3.Auto Mode - Finally, we also offer auto-mode operation, where you can upload your desired dj laser light content to the projector (this can be fully programmed shows, as well as single cues) and set the day, date and time for the projection, and it will be done automatically for you. No trigger, PC or control setup required. A truly auto-play setup, ideal for permanent installations.
Full Color Rgb Laser System
The NewfeelLaser A3 series outdoor laser lights projector animations is a full-color RGB stage outdoor lighting laser projector system . It is a great laser projector for lighting designers as well as special A3 series companies, who want to integrate lasers, into any multimedia setup.



3~15 Watt Full Color DJ Laser Light
The NewfeelLaser A3 series laser is a 3~15 Watt full color RGB diode-based laser light show projector outdoor, with Pangolin's FB4 media server integrated inside a robust housing. Our NewfeelLaser A3 series is ideal for lighting designers as well as special companies, who want to integrate lasers, into any multimedia setup.
Applications
The A3 series is a perfect show outdoor laser projector for small to medium sized venues. In addition, the unitās compact size and multimedia functionality makes it ideal for use in large quantities on tours and related projects where vast numbers of lasers need to be used.
MA3 series can also be used both indoors and outdoors, for the projection of laser graphics, logos, text and laser billboard advertisements. A3 series outdoor laser projector is suitable for venues/crowds of up to 2,500 people in capacity.



Power supply
AC110/220V, 50-60Hz±10%
Rated power
max 500W
Laser power
RGB15W
Laser modulated signal
analog or TTL modulation
Beam diameter at the aperture
<7mm
Beam divergence
<1.3mrad
Laser wavelength
red 638±5nm, green 520±5nm, blue 450±5nm
Scanning system
30K KPPS high-speed scanning
Control mode
international standard ILDA control /DMX512 signal control /self-walk/voice control/master-slave
Control interface
international ILDA DB25 interface, international DXM512, can connect with American Pangolin laser software and tiger, pearl, MA controller, etc.
Safety function
one beam protection, no signal to close the light, etc
Lamp bead color temperature
8000K
Average lifespan of lamp beads
2,000 hours.
Number of DMX control channels
6CH
