Item No. NF760-910 NF760-915 NF760-920
Red Laser R3000mw/638nm R4000mw/638nm R6000mw/638nm
Green Laser G3000mw/525nm G5000mw/520nm G6000mw/520nm
Blue Laser B4000nw/450nm B6000nw/450nm B8000nw/450nm
Scanning system 30kpps 30kpps 30kpps
Newfeel NF760 laser animations
The Newfeel NF760 laser animations is a full-color RGB stage laser system, with an integrated Pangolin FB4 media server and robust housing. It is a great laser projector for lighting designers as well as special FX companies, who want to integrate lasers, into any multimedia setup.
DMX signal conduction prompt function
The device can automatically check whether the DMX signal is connected. When it is detected that there is no DMX signal or the console does not pass, the laser will automatically turn off the light, and the channel numbers on the operation display panel will keep flashing until it is turned on.
ILDA signal intelligent switching
After the device is connected to the ILDA signal line, it can automatically determine whether the ILDA controller (card) is connected. After it is judged that it is connected, it can automatically switch to the ILDA mode and accept the control of the ILDA controller (card). And set up the ILDA information output port to amplify the input signal, so that the connection can be extended infinitely.
Color settings
Through the touch button, all single laser color, two laser colors, and multiple laser colors can be selected.



Applications
The NF760 nod laser is perfect for medium to large indoor venues, as well as for use at small to medium size outdoor shows and festivals (up to around 10,000 people capacity).
The fixture can also be used both indoors and outdoors, for the projection of laser graphics, logos, text, and laser billboard advertisements.
Digital mirror
By touching the keys, you can freely choose the mirror direction of the X-axis and Y-axis of the graph.
Voice-activated action lighting speed adjustment
Through the touch button, the beat speed of the pattern during voice control can be set to meet the requirements of different applications, such as slow shake, DISCO, ROCK and other applications.
Manually adjust the pattern size
Through the X-axis and Y-axis pattern size adjustment knobs of the operation panel, the pattern size can be adjusted to meet the different pattern sizes in different applications.
Safety Protection Embodying safety in details is the proud insistence of SIOT
The new second-generation DREAM series of laser safety protection systems use many advanced technologies to calmly respond to almost any situation, and DREAM can take action in advance.
Safety Knife
The mechanical laser safety knife can cut off the laser light path within 0.01 seconds. Make sure that no single laser spot appears.
Smart single chip chip
With 1T high-speed operation, through complex multi-dimensional operation and comparison, it can intelligently judge the safety status of the laser beam. When the pattern output is less than ±1.5°, it will intelligently turn off the excitation signal of the laser.
Security Lock
Professional laser safety opening lock, only professionals who hold the laser key can open the laser, preventing unauthorized personnel from using the laser.
Remote Lock
Remote safety lock, when the unpredictable situation of the laser occurs, including all electronic safety precautions, the remote INTERLOCK is the most solid line of defense for manual protection. The operator can cut off the low-voltage power by remote hardware and turn off the laser through a long-distance line.
Safety Rings
Safety prevention rings, in case of pressing the handle and other firmware, due to the screw slipping and other reasons, the safety ring is used to prevent the flood control wire rope from the last line of defense to prevent the machine from falling and hurting people.
Handle Design
Double-fastening adjustment handle design, free to adjust the angle, safe and reliable.
Perfect Design
There is no end to the pursuit of perfection. The second-generation DREAM series has a new precision and compact body design and an independent three-layer design, which perfectly separates the laser light path, circuit control and cooling air path independently. The mirror ring is the finishing touch for the square and strong appearance.
Layered Design
Laser light combining layer, silicone seal, IP65 design, dustproof, waterproof, anti-smoke oil.
Super heat dissipation
The large heat dissipation area of 300c㎡ ensures the heat exchange of the laser. After the louvered air inlet and outlet, there are built-in 2 pairs of 3-way high-speed cooling fans, one sucks and one out, which most effectively takes away the exchanged heat energy.
Three-dimensional adjustment frame
Adopt precise three-dimensional adjustment frame. Ensure the quality of the laser spot.



Power supply
AC110/220V, 50-60Hz±10%
Rated power
max 500W
Laser power
RGB10-20W
Laser modulated signal
analog or TTL modulation
Beam diameter at the aperture
max 7mm
Beam divergence
max 1.3mrad
Laser wavelength
red 638±5nm, green 520±5nm, blue 450±5nm
Scanning system
30K-40KPPS high speed scanning
Control mode
international standard ILDA control /DMX512 signal control /self-walk/voice control/master-slave
Control interface
international ILDA DB25 interface, international DXM512 , can connect with American pangolin laser software and tiger, pearl, MA controller,etc.
Safety function
one beam protection, no signal to close the light, etc
Suitable places
big show,dacing hall, club, Bar and other enterntainment venues
Working environment
indoor (-30~40 degrees)
Packing
carton case
What material is the NF760 animated laser beam product case?
It is a metal case with a metal bracket.
Would Newfeel NF760 laser display systems work for an outdoor party?
Yes, it would, but it is not waterproof.
If I am unhappy with the NF760 laser light systems, What can I do about it?
Hi, dear. Any questions, please do not worry, please send the Email to us First by your order ID and tell us what is problem,
we will do our service for you, thank you.
Can I use the Dmx controller to make Newfeel NF760 animation laser 3d patterns?
On the device itself or on the DMX controller.
How to set the NF760 laser club stage strobe light to slave mode?
The mode button on the back.
Does the NF760 laser animations concert stage light have an SD card slot to insert ilda files? Does the device also come with an SD card to change the mode on the computer?
You can choose different items when purchasing: normal configuration/with SD card/with FB4.
