Item No.F8-903AF8-905A
Red LaserR500mw/638nmR1200mw/638nm
Green LaserG800mw/520nmR1200mw/638nm
Blue LaserB1500nw/450nmB3000nw/450nm
Scanning system 15kpps 15kpps
Unmatched Visual Effects
Experience the mesmerizing power of the Newfeel F8 Series DJ laser lights. With dual RGB FAT BEAM effects, create stunning laser color combinations for a captivating laser light show. Perfect for any event, the F8 Series ensures an unforgettable light show.
Seamless Connectivity
Link multiple F8 units effortlessly for synchronized laser light displays. Ideal for stage lights, laser light projectors, and outdoor laser light events, the F8 Series provides seamless integration and superior performance in any setting.
Superior Performance
Featuring 32 built-in patterns, including "Animation Laser" effects, the F8 laser projector delivers sharp visuals. The high-power, full-color semi-professional laser is equipped with DMX control and an internal security setup, simplifying management of multiple devices and other lighting fixtures.
Versatile and Easy to Use
With programmable pan, tilt, and zoom effects, the F8 Series offers endless creativity. Lightweight and easy to install, it's perfect for DJ lasers, stage shows, or home setups. The sealed optics and ultra-quiet fanless system make it low-maintenance and ideal for various installations.
Guaranteed Power Output and Rich Control Modes
Delivering impressive graphics capabilities with a 15 kpps@8° ILDA rating and a maximum scan angle of 50°, the F8 Series produces sharp and intense laser beams.
With multiple control modes and connections via DMX and ILDA, it enables synchronized laser light shows for any event, elevating your visual display to new heights. Ideal for stage lights, party lighting lasers, and laser shows.
Input power
AC90-240, 50-60HZ
Rated power
max 200W
Laser power
RGB1-5W
Laser category
pure solid-state semiconductor laser, with high stability and long life.
Laser modulation
analog modulation or TTL modulation
Laser beam divergence angle
max 1.6mm
Beam divergence
max 1.3mrad
Laser wavelength
red 635 or 638±5nm, green 532 or 520±5nm, blue 450±5nm
Galvanometer scanning system
15KPPS galvanometer
Scanning angle of galvanometer
±25°; input signal ±5V; linear distortion <2%
Laser pattern
128 patterns and animations are built-in on the motherboard.
Control mode
ILDA standard computer laser software/DMX512/sound control/self-propelled/master-slave
Control interface
International ILDA DB25 interface (for an optional function, the cost is increased by RMB50),
can be connected to general laser software such as Pangolin (Pangolin), and the international general DMX512 interface.
DMX channel
6/25CH
DMX special effects
functions such as pen break, strobe, rotation, move, roll, split image, draw gradually, change color, change size, etc.
Suitable places
small and medium-sized performances, bars and other places
Working environment
indoor (minus 10 to minus 35 degrees)
Cooling system
forced cooling by fan
Packing
Carton case
Product size
23.5*20*17CM
Product net weight
3.3K
Carton packaging size
32*30*34CM
Carton packaging weight
6.6kg
Air case packaging size
31x35x40CM
Air case packaging weight
11.2kg
What material is the F8 laser screen type of stage light product case?
It is a metal case with a metal bracket.
Would Newfeel F8 DJ lighting lasers light decoration for party work outdoor?
Yes, it would, but it is not waterproof.
If I am unhappy with the F8 Halloween laser lights stage light drawing, What can I do about it?
Hi, dear. Any questions, please do not worry, please send the Email to us First by your order ID and tell us what is problem,
we will do our service for you, thank you much.
Can I use the Dmx controller to make Newfeel F8 Dmx laser-led stage light 3d patterns?
On the device itself or on the DMX controller.
How to set the F8 stage lasers gaming room lights to slave mode?
The mode button on the back.
Does the F8 laser show equipment concert stage light have an SD card slot to insert ilda files? Does the device also come with an SD card to change the mode on the computer?
You can choose different items when purchasing: normal configuration/with SD card/with FB4.
1. What makes the Newfeel F8 Series laser lights stand out from other laser projectors?
The Newfeel F8 Series laser lights are equipped with dual RGB FAT BEAM effects, creating stunning laser color combinations for captivating light shows. With 32 built-in patterns, including "Animation Laser" effects, and programmable pan, tilt, and zoom features, these lasers deliver unmatched visual effects and versatility for any event. Ideal for stage lights, party lighting lasers, and club lighting.
2. How can I synchronize multiple F8 units for a cohesive light show?
The F8 Series offers seamless connectivity, allowing you to link multiple units effortlessly for synchronized laser light displays. Using DMX control and ILDA connections, you can easily manage and coordinate multiple NF8 lasers, ensuring a unified and impressive light show for stages, parties, and outdoor events. Perfect for DJ lighting and concert lights.
3. Are the F8 Series laser lights easy to install and maintain?
Yes, the F8 Series is designed for ease of use and low maintenance. Lightweight and featuring sealed optics and an ultra-quiet fanless system, these lasers are easy to install and require minimal upkeep. They are perfect for DJ setups, stage shows, and home use, providing an easy and effective lighting solution. Available from leading lighting equipment suppliers.
4. What kind of control modes does the F8 Series offer?
The F8 Series laser lights come with a variety of control modes, including DMX 512, sound activation, automatic sequence, and manual mode for effect selection. This flexibility ensures that whether you are a seasoned professional or a novice, you have full control over your light show. Additionally, the F8 Series supports ILDA/DMX laser control software for more advanced programming and synchronization. Ideal for creating dynamic laser light shows and event lighting.
