Laser modulated signal
analog or TTL modulation
Beam diameter at the aperture
red light 638±5nm, green light 525±5nm, blue light 450±5nm
Galvanometer scanning system
30KPPS high-speed galvanometer
Scanning angle of galvanometer
±30°;input signal ±5V; linear distortion <2%
Hundreds of patterns and animations are built into the motherboard.
The built-in patterns and animations can be updated with SD card.
ILDA standard computer laser software/DMX512/sound control/self-propelled/master-slave
International ILDA DB25 interface and RJ45 network cable interface, which can be connected to
general laser software such as Pangolin, and the international general DMX512 interface.
DMX special effects
broken pen, strobe, rotate, move, scroll, split image, draw gradually, change color, change size, etc.
Safety and intelligence
no signal light is off, DMX signal and PC signal can be switched. With beam protection function,
when the galvanometer fails, it will automatically turn off the light when only one beam of light is emitted.
small and medium performances, bars and other places.
indoor (minus 10 to minus 35 degrees)
The laser is equipped with TEC cooling, and the whole machine is forced to cool by a fan.
