Item No. NF-LBS150
Power 250w
Zoom range 10Ā°-17Ā°
DMX channel 17/20 channels
X axis /Y axis 540 degree /270 degree
Versatile Moving Head Lights with Advanced Features
The Newfeel NF-LBS150 Moving Head LED projector delivers professional-grade performance with its beam moving heads and dynamic zoom lens.
Offering special effect lighting, itās perfect for creating stunning visuals at events, transforming any venue with vivid colors and precise movements.
Whether you need focused spot lights or vibrant washes, this versatile lighting solution adapts effortlessly.
Dynamic Beam and Gobo Effects
With adjustable beam angles from 2Ā° to 28Ā° and advanced spot DMX control, the NF-LBS150 delivers unparalleled flexibility.
Its rotating gobos and 8-color wheel allow for creative patterns and dazzling special effect lighting.
The integrated lighting batten features enhance architectural details, making it ideal for stage setups and live performances.
Professional-Grade Spotlights and Batten Lighting
The NF-LBS150 combines the precision of spot lights with the versatility of batten lighting.
Its DMX512 control and 17/20 DMX channel modes make it a perfect choice for synchronized lighting effects.
Whether used as beam moving heads or as part of a broader lighting batten setup, it delivers professional results every time.



Seamless Control with DMX and Master/Slave Modes
Experience ultimate control with the NF-LBS150ās spot DMX compatibility and Master/Slave functionality.
These features ensure perfect synchronization across multiple moving heads, creating breathtaking displays for concerts, parties, and theater productions.
The built-in software upgrade capability keeps your system up-to-date, ensuring peak performance for every event.
Compact and Reliable Design for Easy Setup
This moving head light is designed for portability and convenience, featuring dual mounting brackets for versatile installation as batten lights or floor-standing units.
The robust build, LCD color display, and precise magnetic positioning system ensure durability and ease of use, even in demanding environments.
Perfect for Events and Architectural Lighting
Whether itās a grand performance, a corporate event, or an intimate party, the NF-LBS150 excels in delivering stunning special effect lighting.
Its beam moving heads and batten lighting capabilities make it a top choice for lighting designers looking to highlight architectural features or create immersive stage visuals.



Input Power supply
AC100-240V, 50/60Hz
Related power
250w
LED Light source
1pc 150W led lamp
Gobo beam angle
Fixed Disc:10Ā°-17Ā°(Zoom Lens)
Rotation Disc
10Ā°-15Ā°(Zoom Lens)
Wash beam angle
15Ā°-28Ā°
Beam Angle
2Ā°/4Ā°/6Ā°/8Ā°/10Ā°/11Ā° 3Ā°/6Ā°/9Ā°/12Ā°/15Ā°(Zoom Lens)
DMX Channel
17/20 channels
DMX Channel Control Mode
DMX,Master/Slave,Sound Control
Software upgrade
through DMX connection update the software
X axis /Y axis
540 degree /270 degree X axis /Y axis
precision
16 bit precision scanning, magnetic positioning system, can accurately automatically correct the Y axis position X axis position
Color Display
LCD color display
DMX signal input & output
3 pin & 5 pin DMX socket
Socket outlet
PowerCon input / output
Protection grade
IP20 linear focusing system
Color disk
8 fixed color plus white, two-way rainbow effect
Pattern plate
1 fixed pattern plates, 7 patterns with white circle, 1 rotating pattern plates, 6 patterns and white circles
Pattern outer diameter
23.8mm
pattern inner diameter
20mm 1 bi-directional rotating 6 prism
Wheel
1 color wheel with 8 colors+open
Inner box size
380x322x470mm
Weight
14KG
The dmx mapping on the manual is incomplete. we need the parameters within the dmx channels in order to set these lights up correctly. do u have those?
Dear, the moving head light stage lighting has the DMX channel mapping, here are the followings:
Channel 1: PAN
Channel 2: TILT
Channel 3: PAN FINE
Channel 4: TILT FINE
Channel 5: DIMMER
Channel 6: STOP / STROBE
Channel 7: FROST
Channel 8: FOCUS
Channel 9: Gobo Change
Channel 10: Gobo Effect
Channel 11: COLOUR WHEEL
Channel 12: COLOUR Effect
Channel 13: PRISM INSERTION
Channel 14: PRISM ROTATION
Channel 15: X/Y Axis speed
Channel 16: Lamp_Control &Reset
When would I receive them?
Dear, it is hard to offer an exact delivery date to you because of the address difference.
But if you order it at the weekend, we would help dispatch the item to you the next Monday, because our warehouse colleagues are out of the office for the weekend.
How much do these weigh each?
Dear, each moving head light stage lighting store is 39.6LBS weight.
How many are there coming?
Dear, it would come with 2 moving head lights, and each of them would come with one package.
Does this need to be attached to the ceiling to work best or can you place on a table or the floor?
A tabletop or floor will work, but mounting higher will give better effect.
If you need more services,please contact us sunny@nfstagelight.com ,we can help you solve all your problems and will do our best service for you,Your satisfaction is our success!
Is this lazer light show compatible with Google android phone?
No, there is no apps for it
What are the dmx in/out for??? and do you recommend ?
A DMX is a controller, yes I recommend it. Look on Youtube for a video on it.
Would like to mount high on wall in a venue and wire it with switch will it start working automatically once powered on?
Yes,it has Auto Mode.
