Item No. NF-L400FYM
Power Supply AC 100-240V,50/60Hz
Power consumption 500W
Light Source 1*400W LED
LED life expectancy more than the 50000 Hours
Electrical Parameters
Input Voltage: AC100-240V, 50/60Hz
Power: 500W
Light Source Performance
Light Source: 1x400W LED
Light Source Lifespan: Average lifespan more than the 50,000 hours
Color Temperature: 2800K-6800K
Color Rendering Index (CRI): CRI ≥ 90, ultra-high color rendering index
Color Characteristics
Color Wheel: 1 color wheel, including 2 colors (blue + magenta)
Linear CTO Color Temperature Adjustment: 2,800K-6,800K
Motion Performance
Horizontal Scan Angle: 540°
Vertical Scan Angle: 270°
16-bit precision scanning
Calibration: The X/Y axis motors utilize the latest magnetic rotary encoding positioning system, achieving precise positioning. The system features automatic error correction to ensure the accuracy of signal feedback.
Beam Characteristics
Focus Angle: 8°-50° linear focus
Dimming: 0-100% linear dimming
Strobe: 1-25Hz/s, high-speed strobe effect
Control Modes
Supports various control functions: DMX/Master-Slave/Auto/Gradient/RDM functions
Channel Mode: 9/11 channels
Interface Design
Power Interface: Optional waterproof single input or hand-in-hand waterproof input/output
Signal Interface: 3-core XLR waterproof input/output
Heat Dissipation Design
Utilizes copper pipe + fan heat dissipation structure with temperature intelligent monitoring technology. The heat dissipation system adjusts automatically, effectively controlling the temperature of the fixture.
Color Temperature
2800K-6800K
Color Rendering Index
CRI≥90
Color
CTO+2 colors(Blue & Rose)
Zoom angle
8°- 50°
Dimmer
0-100% linear electronic dimmer
Strobe
1-12.5Hz/s,fast electronic strobe
Movement
Pan: 540°,16 Bit movement resolution
Tilt: 270°,16 Bit movement resolution
Automatically accurate positioning
Control mode
DMX512,RDM,Sound,Master/Slave,Auto
DMX Channel
9/11 CH
Protection Rating
IP65
Product Size
375*319*560mm,N.W.:16kg
Carton size
400*350*600mm,G.W.:19kg
