Newfeel F4 Array Bar Animation Laser projector

  • The F4 series four eyes RGB professional laser light beam bar is a white outdoor laser light projector RGB array with TTL/Ang modulation and six beam outlets. it is controlled through DMX and ILDA, so it is suitable for easy implementation in existing lighting setups. Each beam output comes with its own XY scan set with 20k @8° ILDA
  • Our F4 series four eyes animated laser effect: The pattern has effects such as broken pen, strobe, rotation, tumbling, moving, stretching, zooming, gradual drawing, speed, color, etc., with pattern size adjustment function, built-in 128 beams and animation patterns, which can be used for beam animation, Laser advertising, laser projection, laser Skynet beam performance, laser line effect.
  • The F4 series four eyes RGB laser bar is equipped with 6 RGB laser lights modules.
  • The F4 series four beam bar ilda lasers are controlled via DMX and ILDA thus it is possible to create many different chasers, beam, and fan laser light effects. the beam array can easily be integrated into an existing lighting setup
$1,680.00
Model: F4-902 (2w/eyes)
F4-902 (2w/eyes)
F4-905 (5w/eyes)
Ask a question Share
Product Manuals
OEM & ODM
Hassle-Free Warranty
Lifetime Customer Support
Guaranteed Safe Checkout
  • PayPal
* You need to pay customs duties when importing goods. Learn More shipping policy
  • Description
  • Specs
  • Faq
  • Reviews
Item No. F4-902 F4-905
Red Laser R500mw/638nm R1200mw/638nm
Green Laser G500mw/520nm G1400mw/520nm
Blue Laser B1000nw/450nm B2500nw/450nm
Scanning system 15KPPS 15KPPS
F4 laser bars
The Newfeel F4 laser bars is a full color RGB ilda laser projector, designed for clients who want an economically friendly laser show system, that still has the power to produce beautiful aerial beam effects, as well as high-resolution laser graphics, logos, and text.
Our F4 Series is perfect for DJs, nightclubs, concerts, and entertainment venues, where you need an impactful and easy-to-use show laser system. F4 Series laser light bar is suitable for venues/crowds of up to 3,000 people incapacity.
nfl-f4-img9
nfl-f4-img8
nfl-f4-img7
Newfeel F4 Series
Newfeel F4 Series laser light beams are incredibly easy to set up and use. And can easily be controlled via ILDA, or via DMX / Artnet.
nfl-f4-img3_b1836580-82ce-48b4-9618-6b64884fc277
nfl-f4-img2_7e2fafc7-c909-4510-8c43-58c07a18c2ef
nfl-f4-img1_3cbef4c6-8bac-486c-8b19-f9845b112262
laser lights
Power supply AC90-240V,50-60Hz±10%
Rated power max 400W
Laser power RGB2/5W*4pcs
Laser modulated signal analog or TTL modulation
Beam diameter at the aperture max 6mm
Beam divergence max 1.3mrad
Laser wavelength red 638±5nm, green 520±5nm, blue 450±5nm
Scanning system 15-30KPPS high speed scanning *4pcs
Control mode DMX512 signal control /self-walk/voice control/master-slave
Suitable places show，dacing hall, club, Bar and other enterntainment venues
Working environment indoor (-30~40 degrees)
Packing carton case
What material is the F4 series four arry programmable animation laser product case?
It is a metal case with a metal bracket.
Would Newfeel F4 concert lasers work for an outdoor party?
Yes, it would, but it is not waterproof.
If I am unhappy with the F4 four lens laser animations, What can I do about it?
Hi, dear. Any questions, please do not worry, please send the Email to us First by your order ID and tell us what is problem, we will do our service for you, thank you.
Can I use the Dmx controller to make Newfeel F4 series laser lights 3d patterns?
On the device itself or on the DMX controller.
How to set the F4 Dmx calculator nightclub lasers to slave mode?
The mode button on the back.
Does the F4 laser show projector stage light rental have an SD card slot to insert ilda files? Does the device also come with an SD card to change the mode on the computer?
You can choose different items when purchasing: normal configuration/with SD card/with FB4.
