Item No. F9-901A F9-902A F9-903A F9-904A F9-905A
Red Laser R300mw/638nm R500mw/638nm R600mw/638nm R1000mw/638nm R1200mw/638nm
Green Laser G80mw/520nm G500mw/520nm G800mw/520nm G1000mw/520nm G1400mw/520nm
Blue Laser B800nw/450nm B1000nw/450nm B1600nw/450nm B2000nw/450nm B2500nw/450nm
Scanning system 15kpps 15kpps 15kpps 15kpps 15kpps
Newfeel F9 Series
The Newfeel F9 laser projection light is a full-color RGB laser light laser projector, designed for clients who want an economically friendly laser show system, that still has the power to produce beautiful aerial beam effects, as well as resolution laser graphics, logos, and text.
Our F9 Series lasers lights are perfect for DJs, nightclubs, concerts, and entertainment venues, where you need an impactful and easy-to-use show laser system. Newfeel F9 5W is suitable for venues/crowds of up to 3,000 people incapacity.
Full Color Laser Lights
Newfeel F9 Series laser projectors are incredibly easy to set up and use. And can easily be controlled via DMX / Artnet.
3D Dance Laser Light Show
The new F9 Series color stage laser lights Halloween projector is mainly used in bar laser light projects and 3D laser dance performances.
This 3W color laser light can be used as a 3D laser dance performance only with the PRO version of the German Fire Phoenix laser control software and a laser performance curtain.
The newly designed 360-degree drop pendant allows this laser light to be installed or hoisted anywhere and at any angle.
Integrated Color Laser Design
This is a color laser show system that is suitable for bars, weddings, and 3D laser light projector dances. It is a high-performance color laser light with all imported lasers. It is suitable for bars and rental customers who require high performance and stability.
The site area is less than 300 square meters, and the floor height is less than 8 meters. Due to the selection of all-diode lasers and integrated color laser design, its brightness and effect can even surpass that of conventional 5W domestic laser lights lamps.



The optical composite light color mixing effect is more delicate and stable
NewFeel Laser's self-developed software has been pre-installed inside the color laser light, which allows you to use longer DMX signal lines for control without interference or graphic jitter.
The advantage of the new F9 3W color laser show projector is that the optical part adopts a fully sealed design.
Even in the harsh bar environment, the e-liquid will not cause damage to any device.
Due to a major technological breakthrough, we canceled the original dust filter design, greatly improving the air intake for heat dissipation, and at the same time, it will not cause poor heat dissipation due to mesh blockage.
The optical platform adopts a floating design, and the optical color mixing effect is more delicate and stable. Normal transportation and use will not have any impact on the combined light, even if it is transported by vibration or rolling, it will hardly affect the optical system. You can safely hang the device, side-mounted or upside down.
Applicable places:
Suitable for bars with high performance and stability requirements.
Indoor large and medium-sized venues such as medium-sized theaters and hotel banquet halls.
The area is less than 300 square meters, and the floor height is less than 8 meters.
Laser Wedding Show.
3D Laser Dance Show.



Power supply
AC110/220V, 50-60Hz±10%
Rated power
max 200W
Laser power
RGB1-5W
Laser modulated signal
analog or TTL modulation
Type of laser
imported semiconductor solid-state laser
Beam diameter at the aperture
<6mm
Beam divergence
max 1.3mrad
Laser wavelength
red 638±5nm, green 520±5nm, blue 450±5nm
Galvanometer scanning system
15-40KPPS high speed scanning
Control mode
international standard ILDA control /DMX512 signal control /self-walk/voice control/master-slave
Control interface
international ILDA DB25 interface, international DXM512 , can connect with American pangolin laser software and tiger, pearl, MA controller,etc.
Safety function
one beam protection, no signal to close the light, etc
Suitable places
show,dacing hall, club, Bar and other enterntainment venues
Working environment
indoor (-30~40 degrees)
Packing
carton case
What material is the F9 laser light showing product case?
It is a metal case with a metal bracket.
Would Newfeel F9 lasers artwork for an outdoor party?
Yes, it would, but it is not waterproof.
If I am unhappy with the F9 RGB laser, What can I do about it?
Hi, dear. Any questions, please do not worry, please send the Email to us First by your order ID and tell us what is problem,
we will do our service for you.
Can I use the Dmx controller to make F9 laser animation display 3d patterns?
On the device itself or on the DMX controller.
How to set the F9 nightclub lasers to slave mode?
The mode button on the back.
Does the F9 laser show system have an SD card slot to insert ilda files? Does the device also come with an SD card to change the mode on the computer?
You can choose different items when purchasing: normal configuration/with SD card/with FB4.
