Item No.SJ5 20W FB4
Red Laserred 638±5nm
Green Lasergreen 520±5nm
Blue Lasergreen 520±5nm
Scanning system 40KPPS
Professional Laser Light Show Projector for Large Outdoor Events
The SJ5 20W IP65 Laser Light Projector with integrated FB4 laser show system is engineered for professional laser light shows in both indoor arenas and outdoor environments. With an impressive 20 watts of RGB optical power, it creates dynamic, full-color visuals that fill large venues and open-air stages with stunning clarity and brightness.
Perfect for concerts, music festivals, city light shows, and outdoor events, this outdoor laser light projector can captivate crowds of up to 30,000 people. Designed with a focus on precision, flexibility, and long-range projection, it ensures your show lights dominate even in brightly lit or foggy environments.
Dynamic Outdoor Laser Lights and 3D Laser Show Performance System
Bring your event to life with mesmerizing outdoor laser lights and immersive 3D laser show effects. The SJ5’s FB4 laser control system allows precise synchronization with music, DMX lighting consoles, or pre-programmed shows, delivering real-time visual harmony.
Whether you're creating an outdoor Christmas light projector display or a futuristic laser swamp installation, the SJ5 offers over 500 built-in laser patterns and supports complex animations and tunnel effects. Its programmable laser light show projector design makes it a favorite among lighting designers for themed shows, festivals, and immersive art exhibitions.
High-Definition Laser Light Projector with RGB Color Mixing for Christmas Shows
The SJ5 combines advanced RGB diode technology with 40KPPS high-speed scanning, allowing you to project crisp text, detailed animations, and brand logos with stunning accuracy. This laser light projector offers smooth RGB color blending, perfect for creating vivid Christmas laser lights outdoor displays and custom seasonal visuals.
Whether used as a holiday projector in a retail plaza, a themed park, or a corporate event, the SJ5 delivers striking image clarity and color richness. Its creative flexibility makes it ideal for designers who want professional results without complex setup.
IP65 Waterproof Outdoor Projector for All-Weather Laser Light Shows
Designed to perform under any condition, the SJ5 20W laser projector features a rugged IP65 waterproof aluminum housing. This waterproof outdoor projector ensures consistent performance in rain, snow, or dust, making it the ultimate tool for outdoor laser light projector applications.
With a sealed optical design that prevents internal condensation and contamination, it guarantees stability during long outdoor installations. From holiday festivals to permanent architectural lighting, the SJ5 ensures reliability and long-term performance in all weather conditions.
Programmable Laser Light Show Projector with FB4 Control Integration
At the core of the SJ5 is its programmable laser light show projector system powered by the FB4 control module. Supporting Ethernet, ArtNet, DMX512, ILDA, and automatic playback, it allows operators to control multiple show lights laser light projectors simultaneously for synchronized effects.
This flexibility enables easy integration into large-scale setups, letting you create multi-fixture laser light show projector outdoor installations or interactive event experiences. With user-friendly software compatibility and onboard memory playback, it’s suitable for both touring professionals and permanent installations.
Safe and Reliable Outdoor Laser Light Projector for Holiday Events
Safety and stability are essential for any laser light show installation. The SJ5 includes built-in safety features such as E-stop emergency shutdown, interlock interface, overheat protection, and automatic power regulation. Compliant with international safety standards, this outdoor laser light projector guarantees peace of mind during continuous operation.
Its modular construction and reinforced optical path ensure optimal beam alignment and reduced maintenance, even after extended use. Whether you’re running a holiday projector setup, a laser swamp attraction, or a multi-venue tour, the SJ5 combines power, precision, and protection for any professional laser application.
Model
SJ5 20W FB4
Power supply
AC110/220V, 50-60Hz±10%
Rated power
max 200W
Laser power
RGB20W
Laser modulated signal
analog modulation
Type of laser
imported semiconductor solid-state laser
Beam size at the aperture
less than 8*6mm
Beam divergence
less than 1.3mrad
Laser wavelength
red 638±5nm, green 520±5nm, blue 455±5nm
Scanning system
40KPPS high speed scanning
Control mode
Integrated American pangolin FB4 /international standard ILDA control /DMX512 signal control /self-walk/master-slave
Control interface
ILDA control, international DXM512 , can connect with tiger, pearl and MA controller,etc.
Safety function
one beam protection, no signal to close the light, etc
Suitable places
dacing hall, club, big show and other enterntainment venues
Laser safety features
Keyed interlock, emission delay, E-Stop,Laser safe key.
Waterproof Grade
IP65
Working environment
indoor /outdoor
Included in the set
1.2M AC power cable, 10M Ethernet rj45 signal cable,1.2M DMX Cable,Light hook, E-STOP Remote with 5M 3-pin XLR cable, Set of 2 safety keys, Interlock , User manual,Pangolin QuickShow laser control and creation software is available for FREE download.
Packing
carton case
Q1: Can this laser projector be used in different countries? Does it require an additional power converter?
A: Yes. The SJ5 20W laser light show projector supports universal voltage (AC 110–220V, 50–60Hz ±10%) and does not require an external transformer. With a maximum rated power of 200W, it provides stable, energy-efficient performance for long-term continuous use, making it suitable for both domestic and international touring applications.
Q2: How bright is the laser output, and what size venue is it suitable for?
A: Equipped with imported solid-state RGB laser modules (Red 6W @ 638nm, Green 8W @ 520nm, Blue 8W @ 455nm), this professional outdoor laser light projector produces precise, vivid colors with excellent beam focus (less than 8×6mm aperture, less than 1.3mrad divergence). It is ideal for large venues such as clubs, night events, concerts, and outdoor laser shows, with outstanding visibility even over long distances.
Q3: What kind of laser effects does it support? Can I create my own patterns or animations?
A: The SJ5 features a 40KPPS high-speed scanner and 500+ built-in laser patterns, delivering both dynamic beams and detailed animations. It supports multiple control modes including FB4 (Ethernet), ILDA, DMX512, Auto, and Master/Slave. You can connect it with major controllers like Tiger, Pearl, and MA, or use the included Pangolin QuickShow software to design your own programmable laser lights, text, and custom animations with ease.
Q4: Is the laser light show projector safe to operate? What safety features are included?
A: Safety is a top priority. The SJ5 is equipped with multiple protection mechanisms, including a keyed interlock, emission delay, emergency stop button (with remote), beam-blocking cover, and auto shutdown when no signal is detected. These features comply with international safety standards, ensuring secure use during professional stage lasers or public outdoor events.
Q5: Can it be used outdoors in rainy or humid conditions?
A: Yes. The SJ5 has an IP65 waterproof and dustproof rating, ensuring reliable operation even in light rain or humid environments. It functions flawlessly for outdoor laser light projector setups and permanent installations. For heavy rain or extreme weather, temporary shelter is recommended to extend the product lifespan.
Q6: What are the best applications for this laser projector?
A: The SJ5 is designed for professional entertainment environments, including nightclubs, outdoor concerts, festivals, corporate events, and laser light shows. Whether it’s for large-scale stage productions or outdoor Christmas displays, this programmable laser light show projector guarantees brilliant and consistent performance.
Q7: What kind of after-sales support is provided?
A: Each SJ5 comes with a full 1-year warranty and lifetime technical support. In case of any issue, our technical team provides remote troubleshooting, firmware updates, and repair service. Keep your purchase receipt to enjoy official warranty coverage and priority customer service.
