Item No. 380 IP
Power frequency 50/60Hz
Power 500W
Waterproof factor IP65
Heat dissipation method air cooling
380 IP is a 500 Watt IP65 Outdoor Rated LED Moving Head Light
380 IP is a 500 Watt IP65 Outdoor Rated LED Moving Head Light Profile with Electronic Focus, Micro Smooth Adjust Focus, Variable CMY+CTO Color Mixing, 4 Blade Framing Shutter, Rotating Gobo, Iris, Frost and 13 High quality lens.
380 IP is a compact multifunctional luminaire with IP65 enclosure rating developed by Newfeel for intensive use outdoors.
It features a new 500W ultra-compact monochrome LED light source, calibrated to 8000K, which delivers metallic white light with an output of 27,400 lumens.
They enable flawless image reproduction and significantly improve distortion caused by shutter blades with wide zooms.
The optics produce a highly uniform flat beam with no hot spots for perfect color combinations, whatever the color combination chosen.
The ultimate versatility of the 380 IP is designed for a wide variety of outdoor
This proprietary system is equipped with a 148mm front lens, has 14 fixed colors + white light, and the color film can be customized arbitrarily. Newfeel has given this next-generation luminaire a new minimalist design, featuring lighter weight die-cast aluminum combined with full weatherproofing to ensure ease of use.
For increased efficiency, the 380 IP features an efficient phase change liquid cooling system with six submersible fans located outside the watertight enclosure. The ultimate versatility of the 380 IP is designed for a wide variety of outdoor and indoor applications, with feature-rich standard equipment including a subtractive CMY color mixing system combined with a variable CTO, and a wheel with six complementary colors for unlimited Vibrant pastels and saturated colors.
The framing section allows precise positioning of the four shutter blades over 100% of the surface area in all positions, allowing the user to frame any object regardless of the position of the light fixture. The image part includes color wheel: 14 fixed colors + white light, color chips can be customized arbitrarily.
Pattern plate: 12 fixed patterns + white light + 5 glass pattern wheels, with pattern shaking and pattern arbitrary positioning functions. Six-color atomization: 1 Six rainbow effects + one fog. 380 IP can be controlled via DMX-RDM, ArtNet or wireless link using LumenRadio's CRMX TiMo RDM.
Newfeel 380 IP gives this next-generation luminaire a new minimalist design in lighter weight die-cast aluminium, combined with full weather protection to ensure ease of use. For increased efficiency, the 380 IP is equipped with an efficient cooling system featuring four submersible fans located outside the watertight casing.
Input power
AC100-240V
Light bulb specification
380W light bulb
Color temperature
8000K
Average lifespan of lamp beads
2,000 hours
Number of DMX control channels
19CH international standard DMX512 channel
DMX connector
3 Pin XLR input and output (hand in hand)
Lighting angle
2°
Dimming
0-100%
Strobe
1-25Hz
Color
6 colors, rainbow effect
Lighting angle
2°
Product size (LxWxH
39*32*61cm
Net weight
20.2KG
Power connector
Hand in hand power input, output
Operation mode
master-slave/auto/DMX
Horizontal scanning
540º, (16bit precision scanning)
Six-color atomization
1 six-color rainbow effect + one atomization
Focusing
Electronic focusing, ultra-fine and smooth adjustment of focus
Type of laser
imported semiconductor solid-state laser
Beam diameter at the aperture
less than 10mm
Beam divergence
less than 1.3mrad
Laser wavelength
red 635 or 638±5nm, green 532 or 520±5nm, blue 450±5nm
Scanning system
25-30KPPS high speed scanning
Control mode
international standard ILDA control /DMX512 signal control /self-walk/master-slave
Safety function
one beam protection, no signal to close the light, etc
Suitable places
land mark bulding, theme park,dacing hall, club, big show and other enterntainment venues
Working environment
outdoor /indoor (-30~40 degrees)
Protection level
IP65
Packing
flight case
